| moq: 20pcs, technical parameter: 565,575,640,725,820,914,1018,1168,1206,1450,1620,1680mm, use for: textile printing, model: 105(105V),125(125V),155(155V),185(185V)mesh |
| Detailed Trade Lead Description |
Detailed Information：
|
Mesh Series：105(105V),125(125V),155(155V),185(185V)mesh
|
Length Series：1450-3500mm
|
Repeat Series：565,575,640,725,820,914,1018,1168,1206,1450,1620,1680mm
|
Note:specific specification can be produced according to customers requirements as well as can produce in line with customers extraordinary requirements.
|
Characteristic: High open area,good toughness,elasticity and precise plate making etc.,Used in printing fine line,pattern,geometrical design,half tone etc for rotary printing machine.
目數(Mesh )
|
厚度(μm)
|
開孔率(%)
|
孔徑(μm)
|
105/105V
|
105
|
15
|
101
|
105H/105VH
|
115
|
15
|
101
|
125/125V
|
100
|
15
|
79
|
125H/125VH
|
110
|
15
|
79
|
155
|
95
|
13
|
60
|
155V
|
95
|
13
|
60
|
185
|
95
|
11
|
47
|
185V
|
95
|
11
|
47
|
|
Notes:
1. All screen with "V" the hole order is 45 angle. Especially used in printing pane and line, geometrical figure, etc.
2. All kinds of screen can be used for 5~7 times repeatedly.
|
|
|
|
